Description:
The 140g pre-saturated wiper is made of 100% polyester with a certain proportion of industrial solvents such as alcohol IPA,. Cleaner than standard clean room wiper., soaked with different purity of IPA and industrial alcohol. Customers can choose solvent according to their own needs,
Features
—Soft and do not scrach the surface
—Provide sufficient dry and wet strength.
—Laser sealed/ultrasonic sealed edge. low ion release
—High chemical resistance
Applications:
—Suitable for classrooms
—PCB、SMT、semiconductor fabrication,electronic assembly production and office
—Cleaning of surfaces to control submicron particles,fiber,and chemical residue
Technical Data:
Performance characteristics
Basic Weight 140gsm
Thickness 0.48mm
Solvent Content 70%IPA:30%DI
Period of validity 2 years
Absorbency Rate & Capacity
(IEST-RP-CC 004.3)
Sorptive capacity NA
Nonvolatile Residue,NVR
(IEST-RP-CC 004.3. short term extraction)
IPA Extractant(100ml IPA at ambient temp for 24 hrs) 0.065mg/g
DIW Extractant(100 ml DI water at ambient temp for 24 hrs) 0.025mg/g
NO Silicon Oil,Amide and DOP detected
FTIR
Ion Content
(IEST-RP-CC 004.3. short term extraction)
Chloride(CI) 0.000450 mg/g
Nitrates(NO3) 0.000050 mg/g
Nitrite(NO2) 0.000050 mg/g
Sulphate(SO4) 0.000400 mg/g
Sodium(NA) 0.000095 mg/g
Potassium(K) 0.000108 mg/g
Mognesium(Mg) 0.000103 mg/g
Calcium(Ca) 0.000065 mg/g
Ordering information:
|
P/N
|
DESCRIPTION
|
PCS/BAG
|
BAG/CASE
|
Carton Size
|
|
PR-POLY-140-1009D-LCE
|
140g pre-saturated wiper 100% polyester, laser cut Size:9”x9
|
150
|
10
|
47x23.5x45cm
|
|
PR-POLY-140-1006D-LCE
|
140g pre-saturated wiper 100% polyester, laser cut Size:6”x6”
|
150
|
20
|
31x31x45cm
|
|
PR-POLY-140-1004D-LCE
|
140g pre-saturated wiper 100% polyester, laser cut Size:4”x4”
|
600
|
10
|
47x23.5x45cm
|
|
PR-POLY-140-1009D-UCE
|
140g pre-saturated wiper 100% polyester, ultrasonic cut Size:9”x9
|
150
|
10
|
47x23.5x45cm
|
|
PR-POLY-140-1006D-UCE
|
140g pre-saturated wiper 100% polyester, ultrasonic cut Size:6”x6”
|
150
|
20
|
31x31x45cm
|
|
PR-POLY-140-1004D-UCE
|
140g pre-saturated wiper 100% polyester, ultrasonic cut Size:4”x4”
|
600
|
10
|
47x23.5x45cm
|
Wiper series
