Specification of Antistatic Tabby Fabric
|
No.
|
Parameter
|
Unit
|
5mm antistatic grid Tabby fabric
|
|
1.
|
Composition
|
|
98% polyester
2%conductive fibre
|
|
2.
|
Width
|
|
1.52M
|
|
3.
|
Surface density (weight)
|
G/m2
|
90
|
|
4.
|
Weave
|
|
2/2 tabby
|
|
5.
|
Weave density
|
Warp
|
Threads/ 1cm
|
68
|
|
Weft
|
Threads/ 1cm
|
41
|
|
6.
|
Yarn
|
Warp
|
|
75D 48F
|
|
Weft
|
|
75D 48F
|
|
7.
|
Conductive
Fiber (E.C.F.)
|
Warp
|
|
22T/3-9R1
|
|
Weft
|
|
22T/3-9R1
|
|
8.
|
Shrinkage (for want of washings, dry-cleaners, sterilization)
|
%
|
<2
|
|
9.
|
Air Permeability
|
|
>10
|
|
10.
|
Surface resistivity
|
Ohms
|
<106
|
|
Tribo-charge
|
V
|
<300
|
|
11.
|
Tearing
Strength
|
Warp
|
Kg
|
165
|
|
Weft
|
Kg
|
73
|
|
12.
|
Electric charge quantity
|
Uc/m2
|
0.18
|
|
|
Colour choice:
|
5MM GRID
|
|
STFN001
|
WHITE
|
|
STFN002
|
LIGHT BLUE
|
|
STFN003
|
PINK
|
|
STFN021
|
FLUORESCENT WHITE
|
|
STFN006
|
DARK BLUE
|
|
STFN008
|
SKY BLUE
|
|
STFN067
|
LIGHT BROWN
|
|
STFN068
|
LIGHT AQUA BLUE
|
|
STFN012
|
NAVY BLUE
|
|
STFN022
|
MIDDLE BLUE
|
|
STFN031
|
DARK BLUE
|
|
STFN032
|
DARK GREEN
|
|
STFN033
|
GREEN
|
|
STFN034
|
LIGHT YELLOW
|
|
STFN035
|
DARK YELLOW
|
|
STFN036
|
ORANGE
|
|
STFN037
|
OLIVE GREEN
|
|
STFN060
|
DARK GREY
|
|
STFN061
|
MINT GREEN
|
|
STFN062
|
LIGHT GREY
|
|
STFN063
|
GREEN
|
|
STFN064
|
GREY GREEN
|
|
STFN065
|
APPLE GREEN
|
|
STFN066
|
MAROON
|
Ordering information:
Packing:1roll/poly bag/ctn.
